WR15 Orthogonal Waveguide To Coaxial Adapter for millimeter wave System Interconnection

This product is a professional Waveguide to Coaxial Adapter featuring an orthogonal design for millimeter wave applications. The adapter operates across the 50GHz to 75GHz frequency band in the WR15 waveguide size and is constructed from copper with gold plating for excellent conductivity and corrosion resistance. As an Orthogonal Waveguide Coaxial Adapter, it provides a 90 degree interface orientation that enables seamless transition between WR15 waveguide and standard coaxial systems. The component features a FUGP620 flange on the waveguide side and a 1.0 K type coaxial connector, ensuring compatibility with precision millimeter wave test equipment and system interfaces. This adapter serves as both an interface bridge and a performance assurance device, providing low loss, high isolation, and broadband operation at millimeter wave frequencies.

This Orthogonal Waveguide Coaxial Adapter delivers solid electrical performance across its operating frequency range. The Voltage Standing Wave Ratio is rated at 1.6 or lower, ensuring good impedance matching with minimal signal reflection. The insertion loss is 1.0dB or lower, allowing efficient signal transmission through the transition. The average power handling is suitable for low power signal processing in test and measurement applications. The gold plated copper construction provides superior conductivity and protects against oxidation, ensuring long term reliability at millimeter wave frequencies. The orthogonal design is ideal for space constrained installations where direct inline connections are not practical, offering flexible system layout options while maintaining excellent electrical performance. The wide selection of available coaxial connector types including SMA K, 2.92 K, N K, 2.4 K, and 1.0 K ensures compatibility with standard test equipment.

One clear strength of this Waveguide to Coaxial Adapter is its ability to solve interconnection challenges between different transmission line types at millimeter wave frequencies. It is widely used in communication systems, radar systems, and microwave measurement fields for reliable system interconnection. The WR15 to 1.0 K transition is particularly suitable for V band applications where waveguide to coaxial interface is required. The adapter maintains good phase response and low attenuation when properly matched to the system impedance. The standard flange interface ensures compatibility with common WR15 waveguide components. This component is also available with custom options for frequency band, connector type, and finish upon request.

In practical use, this Orthogonal Waveguide Coaxial Adapter handles professional millimeter wave system integration tasks very well. For test laboratories, it provides reliable interface between waveguide devices and coaxial test equipment during measurement setups. For radar systems operating at V band frequencies, it enables connection between waveguide components and coaxial receiver chains. For Satellite Communication ground stations, it provides the interface needed between waveguide feed networks and coaxial transceivers. The gold plated copper construction provides excellent durability and conductivity at millimeter wave frequencies. The orthogonal design offers space saving installation options in compact systems. The standard flange interfaces mate securely with common WR15 components. This Waveguide to Coaxial Adapter stands as a solid example of a well designed interface solution for millimeter wave system interconnection applications.
